TP-Link Omada EAP225 AC1350 Wi-Fi 5 Wireless MU-MIMO Gigabit Ceiling Mount Access Point

TP-Link Omada EAP225 AC1350 Wi-Fi 5 Wireless MU-MIMO Gigabit Ceiling Mount Access Point

Upgrade your business or home network with the TP-Link Omada EAP225 AC1350, a professional dual-band Wi-Fi 5 access point designed to provide fast, reliable and manageable wireless connectivity.

The EAP225 delivers combined wireless speeds of up to 1,317 Mbps — up to 450 Mbps on 2.4 GHz and 867 Mbps on 5 GHz — and uses 802.11ac Wave 2 MU-MIMO technology to communicate with multiple devices simultaneously.

With Omada centralized management, PoE support, seamless roaming, guest networking and advanced wireless technologies, the EAP225 is suitable for offices, hotels, schools, restaurants, shops, homes and other environments requiring dependable Wi-Fi.

Key Features

🚀 AC1350 Dual-Band Wi-Fi 5

Enjoy high-speed wireless connectivity across two bands:

2.4 GHz: Up to 450 Mbps

5 GHz: Up to 867 Mbps

Combined: Up to 1,317 Mbps

IEEE 802.11ac/n/g/b/a compatible

Actual wireless performance depends on environmental conditions, network traffic, connected devices and other factors.

📡 MU-MIMO Technology

The EAP225 uses 802.11ac Wave 2 MU-MIMO technology, allowing the access point to communicate with multiple compatible devices at the same time rather than serving them sequentially. This makes it well suited to environments with multiple users and connected devices.

☁️ Omada Centralized Management

Integrate the EAP225 into the TP-Link Omada ecosystem for centralized network management and monitoring. Depending on the Omada setup and controller used, administrators can manage multiple network devices from a unified interface.

The Omada App also provides convenient management from a smartphone or tablet.

🔌 Flexible PoE Installation

The EAP225 supports IEEE 802.3af PoE and 24V Passive PoE, allowing power and data to be delivered through Ethernet for a cleaner installation.

A Passive PoE adapter is included with the product according to TP-Link’s specifications.

🔄 Seamless Roaming

When deployed with the appropriate Omada SDN controller and compatible configuration, seamless roaming helps devices maintain connectivity as users move between access points. This is particularly useful in larger offices, hotels, schools and multi-AP installations.

📶 Advanced Wireless Technologies

The EAP225 supports several technologies designed to improve network efficiency and wireless performance, including:

MU-MIMO

Beamforming

Band Steering

Airtime Fairness

Load Balancing

QoS/WMM

Rate Limiting

Automatic Channel Assignment

Omada Mesh*

🔐 Secure Guest Wi-Fi

Create a dedicated guest wireless experience with features such as captive portal authentication, wireless isolation, access control, MAC filtering and SSID-to-VLAN mapping.

The Omada platform can also support authentication options such as voucher, SMS and other captive-portal methods depending on the controller and configuration.

🏢 Ceiling or Wall Mounting

The compact ceiling-mount design allows the EAP225 to be installed discreetly in offices, classrooms, hotels, reception areas, restaurants and homes. Mounting kits are included.

—

Ideal Applications

🏢 Offices & Corporate Networks

Provide wireless connectivity for employees, visitors, laptops, smartphones, VoIP devices and other business equipment.

🏨 Hotels & Guest Houses

Deploy multiple access points to create managed Wi-Fi throughout guest and common areas.

🏫 Schools & Educational Institutions

Support classrooms, staff offices, student devices and other connected equipment.

🏪 Shops & Commercial Spaces

Provide reliable wireless access for staff and customers while maintaining network separation.

🏠 Homes & Large Residences

Create a centrally managed Wi-Fi network with additional access points where wider coverage is required.

🍽️ Restaurants & Cafés

Provide managed customer Wi-Fi while keeping guest traffic separated from business network resources.

—

Technical Specifications

Specification Details

Model TP-Link Omada EAP225

Wi-Fi Standard IEEE 802.11ac/n/g/b/a

Wi-Fi Generation Wi-Fi 5

Wireless Class AC1350

2.4 GHz Speed Up to 450 Mbps

5 GHz Speed Up to 867 Mbps

Combined Wireless Rate Up to 1,317 Mbps

MU-MIMO Yes

Beamforming Yes

Band Steering Yes

Airtime Fairness Yes

Gigabit Ethernet 1 × Gigabit RJ-45

PoE 802.3af/at PoE and 24V Passive PoE*

Antennas Internal omni-directional antennas

Mounting Ceiling / Wall

Multiple SSIDs Up to 16 total, 8 per band

Omada App Yes

Centralized Management Omada Controller / Cloud-based options

Omada Mesh Supported with compatible Omada setup

Seamless Roaming Supported with compatible Omada setup

Maximum Power Consumption Up to 12.6 W depending on version/region

Dimensions 205.5 × 181.5 × 37.1 mm

Operating Temperature 0°C–40°C

Specifications can vary by hardware revision. TP-Link lists multiple EAP225 revisions, so confirm the exact hardware version supplied before installation if a particular feature is critical.

—

Why Choose the TP-Link Omada EAP225?

The TP-Link Omada EAP225 AC1350 combines business-class wireless features with flexible deployment and centralized management. It is a practical choice for installations where you need:

Fast dual-band Wi-Fi

Support for multiple users

Gigabit wired connectivity

PoE-powered installation

Centralized network management

Guest Wi-Fi functionality

Multiple SSIDs

Seamless roaming

Advanced wireless optimization

Ceiling or wall mounting

Whether you’re building a small office network or deploying multiple access points across a larger property, the EAP225 can form part of a scalable Omada networking solution.

What’s in the Box?

According to TP-Link’s listed package contents:

1 × TP-Link Omada EAP225 Access Point

Passive PoE Adapter

Power Cord

Mounting Kits

Installation Guide

TP-Link Omada EAP225 AC1350 Wi-Fi 5 Access Point delivers fast dual-band wireless connectivity with up to 1,317 Mbps combined speed. It features MU-MIMO, Gigabit Ethernet, PoE support, centralized Omada management, seamless roaming and secure guest networking, making it ideal for offices, hotels, schools, businesses and homes.

Bring reliable, professionally managed Wi-Fi to your network with the TP-Link Omada EAP225.
